High Perfermance Shock Test Systems Shock Tester For Half Sine Test 30000G Duration 0.1ms

Name: High Perfermance Shock Test Systems Shock Tester For Half Sine Test 30000G Duration 01ms
Brand: LABTONE
Price: 1 USD

Wholesale High Perfermance Shock Test Systems Shock Tester For Half Sine Test 30000G Duration 0.1ms from china suppliers

Brand Name : LABTONE

Model Number : G-HSKT30

Certification : CE, ISO

Place of Origin : CHINA

MOQ : 1SET

Price : Negotiable

Payment Terms : T/T

Supply Ability : 15 Sets / Month

Delivery Time : 45 working days

Packaging Details : International wooden case

Name : High Perfermance Shock Test Systems Shock Tester For Half Sine Test 30000G Duration 0.1ms

Table size : 250 x 250 cm

Specimen max weight(kg) : 10kg

Shock pulse : half sine

Acceleration : 30000G

Pulse duration range (ms) : 0.1-11ms

Contact Now

High Perfermance Shock Test Systems Shock Tester For Half Sine Test 30000G Duration 0.1ms

High Perfermance Shock Test System Main applications: mobile phones, computer components, optical components, connectors, etc, also used to test the shock absorbance ability of materials

Light emitter and light receptor will detect presence of human in danger zone. Operation will be stopped to protect personal safety.

High Perfermance Shock Test Systems Main Features

1) User-friendly touching screen operation.Half sine, square waveform shock pulse programmers.High rigidity shock tables.

2) Half sine, square waveform shock pulse programmers.

3) High rigidity shock tables.

4) A full range of safety features.

5) Apply air and hydraulic pressurization, strong friction brake avoiding secondary shock .

6) Apply air spring suspension, hydraulic damping shockproof system, no shock impact on the surrounding, without foundation

High Perfermance Shock Test Systems

Model	HSKT10	HSKT10D	HSKT15	HSKT30	HSKT35
Table Size(mm)	200 x 250	300 x 300	250 x 250	250 x 250	250 x 250
Max. Payload (kg)	10	25	10	10	10
Shock Pulse	Half Sine Wave
Acceleration Range(G)	20~2000 (bare table)	20~10000 (bare table)	20~15000 (bare table)	20~30000 (bare table)	20~35000 (bare table)
Pulse Duration(ms)	0.2~18		0.1~11

Standard Shock Test systems

Model		SKT30	SKT50	SKT100	SKT200	SKT300	SKT600	SKT1000
Table Size (cm)		40 x 40	50 x 60	70 x 80	100 x 100	120 x 120	150 x 150	200 x 200
Max. Specimen Weight(kg)		30	50	100	200	300	600	1000
Max. Acceleration (G)	Half Sine	600	600	600	500	500	300	300
	Saw-tooth	100	100	100	100	100	100	100
	Square		150	150	150	100	100	100
Pulse duration (ms)	Half Sine	30—0.5	30～1	30～1	30～2	20～3	20～3	20～3
	Saw-tooth	18～6	18～6	18～6	18～6	18～6	16～6	18～6
	Square		30～6	30～6	30～6	30～6	30～6	30～6
Controller cabinet dimension(cm)		W55D50H80
Machine weight(Kg)		1900	2300	3200	4200	8500	15500	21500
Power supply		3(phase) AC380V 50/60Hz Compressed air 0.5～0.8MPa
Standards		GB/T2423-2008 GJB1217 GJB360.23 GJB150 GJB548 MIL-STD-202F IEC-68-2-27 MIL-STD-883E MIL-STD-810F ISTA UL

Our Service

Pre-Sales Service

* Technical consultation: test method, laboratory planning and suggestion.

* Equipment selection: selection scheme, FAQ.

* View our Factory

After-Sales Service

* Training how to install the machine, training how to use the machine.

* Engineers available to service machinery overseas.
